High Quality Building Steel Tube
Description
Our scaffolding steel pipes are made of high-strength carbon steel, with an outer diameter of 48.3mm and a wall thickness ranging from 1.8 to 4.75mm. They feature excellent stability and durability and are suitable for various industries such as construction, shipping, and petroleum. The product has a smooth surface and strong anti-rust ability. It is coated with a high-zinc coating (280g, higher than the industry standard of 210g), ensuring a longer service life. It can be used in combination with various scaffolding systems such as ring locks and cup locks, and is the preferred material for safety and reliability in modern construction.
Product parameters
Material: High-carbon steel, resistance welding
Outer diameter: 48.3mm (Standard specification for scaffolding pipes)
Wall thickness: 1.8mm - 4.75mm (customizable according to requirements
Surface treatment: High-zinc coating (280g/㎡, higher than the industry
standard of 210g), rust-proof and corrosion-resistant
Features: Smooth surface, free of cracks, resistant to bending, and in compliance with national material standards
Applicable systems: ring lock, cup lock, coupler (tubular) system, etc
Application fields: Construction, shipbuilding, oil pipelines, steel structure engineering, etc
Steel pipes are of high strength and durability, making them the preferred
scaffolding material for modern construction.
Size as following
|
Item Name |
Surface Treament |
Outer Diameter (mm) |
Thickness (mm) |
Length(mm) |
|
Scaffolding Steel Pipe |
Black/Hot Dip Galv.
|
48.3/48.6 |
1.8-4.75 |
0m-12m |
|
38 |
1.8-4.75 |
0m-12m |
||
|
42 |
1.8-4.75 |
0m-12m |
||
|
60 |
1.8-4.75 |
0m-12m |
||
|
Pre-Galv.
|
21 |
0.9-1.5 |
0m-12m |
|
|
25 |
0.9-2.0 |
0m-12m |
||
|
27 |
0.9-2.0 |
0m-12m |
||
|
42 |
1.4-2.0 |
0m-12m |
||
|
48 |
1.4-2.0 |
0m-12m |
||
|
60 |
1.5-2.5 |
0m-12m |
Product advantages
1. High strength & Durability: Made of high-carbon steel through resistance welding, it has strong compressive resistance, is not prone to deformation, and is safer and more stable than bamboo scaffolding.
2. Anti-rust and anti-corrosion: High-zinc coating (280g/㎡, superior to the common 210g in the industry), corrosion-resistant, and extends service life.
3. Standardization & Strong universality: Complies with national material standards (such as outer diameter 48.3mm), and is compatible with various scaffolding systems (ring lock, cup lock, pipe clamp type, etc.).
4. Wide application: It is suitable for large-scale projects such as construction, shipping, petroleum, and steel structures, meeting the high-load demands of modern construction.
Compared with traditional bamboo scaffolding, steel pipes have significant advantages in terms of safety, load-bearing capacity and service life, and are the first choice for modern engineering
