Mobile Scaffolding System Castor Wheel

Short Description:

A scaffolding castor wheel with a 200mm or 8 inchs diameter is a crucial components for mobile scaffolding system tower , facilitating easy movement and secure positioning.

Scaffolding caster wheel include different types base on materials, have rubber, PVC, Nylon, PU, Cast Iron etc. Normal size is 6 inchs and 8 inchs. We also provide OEM and ODM service. Base on your requirements, we can produce what you need.

MOQ: 100 pcs

Packing: woven bag or carton

Raw Materials: Rubber/PVC/Nylon/PU etc

Send email to us

Product Detail

Product Tags

Key Features

Wheel Diameter: 150mm and 200mm (6 inch and 8 inch)
Tube compatibility : They are designed to fit standard scaffolding tubes securely, featured with a wheel-tube fixing system. Mainly use for ringlock system, alum tower and frame system.
Locking Mechanism: Heavy duty braking system to ensure stability and prevent unintended movement ( dual brakes or other equivalent system).
Materials: The wheel is made from high-strenght materials such as polyethylene or rubber or nylon or cast iron for durability and load-bearing capacity, the other components are made from materials which shall have a good resistence to be protected against, atmospheric corrosion and shall be free of any impurities and defect which might affect their satisfactory use.
Load Capacity: Rated for static load capacity of 400kg, 450kg, 700kg, 1000kg etc.
Swivel Function: some types wheel allows for 360 degree rotation with easy manoeuvrability.
Complaince: They are designed to conform to international standards, such as DIN4422, HD 1044: 1992, AND BS 1139 : PART 3 /EN74-1 standard.

Basic Information

Series	Wheel Dia.	Wheel Material	Fasten Type	Brake Type
Light Duty Caster	1''	Aluminium core polyurethane	Bolt hole	Double Brake
Heavy Duty Caster	1.5''	Cast iron core polyurethane	Fixed	Back Brake
Standard Industrial Caster	2''	Elastic Rubber	Grip Ring Stem	Side Brake
European type Industrial Caster	2.5''	Polyer	Plate Style	Nylon Pedal Double Brake
Stainless steel Caster	2.5''	Nylon	Stem	Position Lock
Scaffolding Caster	3''	Plastic	Long Stem	Front Brake
	6''	Plastic Core Polyurethane	Threaded Stem	Nylon Front Brake
	8''	Polyvinyl Chloride	Long Threaded Stem
	12''
