BS1139 Scaffold Tubes – High-Strength Pipes for Construction
Premium-Grade Scaffolding Tubes
Huayou ranks among China's leading scaffold tube manufacturers, backed by ten years of industry expertise and substantial inventory capacity.
Our scaffold tubes are produced from premium-grade materials, including EN10219-1 aluminum and high-strength steel. We offer both 3.0mm and 4.0mm thickness options in EN39-compliant grades to suit diverse project requirements.
Standard galvanized finish ensures superior corrosion resistance and extended service life. For the oil and gas sector, we supply Type 3 (48.3×3.2mm, S355) and Type 4 (48.3×4.0mm, S235) tubes, fully compliant with EN10219 and international industry standards.
Beyond galvanized options, we also provide black and painted tubes ideal for façade, putlog, and walk-through scaffolding applications. These are widely used in both industrial and civil construction projects.
Our tubes serve as raw materials for all major scaffolding systems including cuplock, ringlock, kwikstage, shoring, and quick-lock. Custom lengths are available up to 6.0m, with complimentary cutting service.
Manufactured to EN39 Pipe European quality standards, every order is guaranteed to meet local and international specifications. We provide complete production control and dedicated after-sales support.
Contact us today to discuss your scaffolding tube requirements.
BS1139 Standard Galvanized Scaffold Tube OD48.3mm Type 4
| No. | Items | Dimension(mm) |
| W4B100 | 1.0m Gal Scaffold Tube | OD48.3×4.0x1000 |
| W4B150 | 1.5m Gal Scaffold Tube | OD48.3×4.0x1500 |
| W4B250 | 2.5m Gal Scaffold Tube | OD48.3×4.0x2500 |
| W4B300 | 3.0m Gal Scaffold Tube | OD48.3×4.0x3000 |
| W4B350 | 3.5m Gal Scaffold Tube | OD48.3×4.0x3500 |
| W4B400 | 4.0m Gal Scaffold Tube | OD48.3×4.0x4000 |
| W4B450 | 4.5m Gal Scaffold Tube | OD48.3×4.0x4500 |
| W4B550 | 5.5m Gal Scaffold Tube | OD48.3×4.0x5000 |
| W4B600 | 6.0m Gal Scaffold Tube | OD48.3×4.0x6000 |
| W4B640 | 6.4m Gal Scaffold Tube | OD48.3×4.0x6400 |
OD48.3mm Black Scaffold Tubes
| Code | Items | Dimension | Length |
| W4B1H | Black Scaffold Tube Type 4 (1-2m) | OD48.3×4.0mm | 1-2m |
| W4B2H | Black Scaffold Tube Type 4 (2-3m) | OD48.3×4.0mm | 2-3m |
| W4B3H | Black Scaffold Tube Type 4 (3-4m) | OD48.3×4.0mm | 3-4m |
| W4B4H | Black Scaffold Tube Type 4 (4-5m) | OD48.3×4.0mm | 4-5m |
| W4B5H | Black Scaffold Tube Type 4 (5-6m) | OD48.3×4.0mm | 5-6m |
| W4B6H | Black Scaffold Tube Type 4 (6-7m) | OD48.3×4.0mm | 6-7m |
Galvanized Scaffold Tube Type 3
| No. | Items | Dimension(mm) |
| W3B100 | 1.0m Galvanized Pipe Type 3 | OD48.3×3.2×1000 |
| W3B150 | 1.5m Galvanized Pipe Type 3 | OD48.3×3.2×1500 |
| W3B200 | 2.0m Galvanized Pipe Type 3 | OD48.3×3.2×2000 |
| W3B250 | 2.5m Galvanized Pipe Type 3 | OD48.3×3.2×2500 |
| W3B300 | 3.0m Galvanized Pipe Type 3 | OD48.3×3.2×3000 |
| W3B350 | 3.5m Galvanized Pipe Type 3 | OD48.3×3.2×3500 |
| W3B450 | 4.5m Galvanized Pipe Type 3 | OD48.3×3.2×4500 |
| W3B500 | 5.0m Galvanized Pipe Type 3 | OD48.3×3.2×5000 |
| W3B550 | 5.5m Galvanized Pipe Type 3 | OD48.3×3.2×5500 |
| W3B600 | 6.0m Galvanized Pipe Type 3 | OD48.3×3.2×6000 |
| W3B640 | 6.5m Galvanized Pipe Type 3 | OD48.3×3.2×6500 |
OD48.3 x 3.2mm Scaffold Black Tubes
| Code | Items | Dimension | Length |
| W3B1H | 1-2m Black Tube Type 3 | OD48.3×3.2mm | 1-2m |
| W3B2H | 2-3m Black Tube Type 3 | OD48.3×3.2mm | 2-3m |
| W3B3H | 3-4m Black Tube Type 3 | OD48.3×3.2mm | 3-4m |
| W3B4H | 4-5m Black Tube Type 3 | OD48.3×3.2mm | 4-5m |
| W3B5H | 5-6m Black Tube Type 3 | OD48.3×3.2mm | 5-6m |
| W3B6H | 6-7m Black Tube Type 3 | OD48.3×3.2mm | 6-7m |
Painted Scaffold Tube
| Code | Item | Dimension(mm) | Length |
| W3B1P | Painted Scaffold Pipe 1-2m | OD48.3×3.2/4.0 | 1-2m |
| W3B2P | Painted Scaffold Pipe 2-3m | OD48.3×3.2/4.0 | 2-3m |
| W3B3P | Painted Scaffold Pipe 3-4m | OD48.3×3.2/4.0 | 3-4m |
| W3B4P | Painted Scaffold Pipe 4-5m | OD48.3×3.2/4.0 | 4-5m |
| W3B5P | Painted Scaffold Pipe 5-6m | OD48.3×3.2/4.0 | 5-6m |
| W3B6P | Painted Scaffold Pipe 6-7m | OD48.3×3.2/4.0 | 6-7m |
Company Advantages
Our manufacturing facility is strategically situated in Tianjin, offering direct access to both steel raw material suppliers and Tianjin Port – the largest port in northern China. This prime location significantly reduces material procurement costs and facilitates efficient global shipping.
Our production team consists of certified welders and skilled technicians, supported by a rigorous quality control department that ensures every scaffolding product meets the highest standards of workmanship.
Our sales personnel bring over eight years of specialized experience in the scaffolding industry, delivering professional, responsive, and trustworthy service to clients worldwide.
We distinguish ourselves through competitive pricing, an agile sales force, dedicated quality assurance, robust manufacturing capabilities, and premium-grade products. As an ISO and SGS-certified ODM manufacturer, we offer a diverse range of ringlock scaffolding systems constructed from stable steel materials.
Our long-term vision is to establish our brand as an industry leader and pioneer. We are confident that our proven manufacturing expertise will earn the lasting trust of our customers. We look forward to collaborating with you to build a brighter future together.
As a China-based ODM manufacturer of prop and steel prop systems, we stay attuned to evolving market trends through continuous innovation and managerial excellence. We are committed to on-time delivery, cutting-edge design, uncompromising quality, and full operational transparency. Our guiding principle is to provide optimal solutions within agreed timeframes.
