High Quality Drop Forged Connectors Ensure A Secure And Secure Connection
Product Introduction
As the cornerstone of steel tube and fitting systems, these British Standard scaffolding fittings have been a trusted choice in the construction industry for many years. Our high quality drop forged connectors ensure a safe and secure connection, providing the stability and safety required for construction projects.
Our company understands the importance of quality and reliability in scaffolding products. That’s why our connectors and accessories are crafted using advanced drop-forging technology for exceptional strength and durability. Whether you’re working on a small residential project or a large commercial construction site, our scaffolding accessories are built to withstand the toughest conditions, ensuring your scaffolding system is always safe and reliable.
Since we established our export company in 2019, we have successfully expanded our business to nearly 50 countries around the world. Our commitment to quality and customer satisfaction has enabled us to establish a comprehensive procurement system to ensure that we can meet the diverse needs of customers in different markets. We pride ourselves on providing high-quality products that not only meet but also exceed industry standards.
Scaffolding Coupler Types
1. BS1139/EN74 Standard Drop Forged scaffolding Couplers and Fittings
| Commodity | Specification mm | Normal Weight g | Customized | Raw Material | Surface treatment |
| Double/Fixed coupler | 48.3x48.3mm | 980g | yes | Q235/Q355 | eletro Galvanized/ hot dip Galvanized |
| Double/Fixed coupler | 48.3x60.5mm | 1260g | yes | Q235/Q355 | eletro Galvanized/ hot dip Galvanized |
| Swivel coupler | 48.3x48.3mm | 1130g | yes | Q235/Q355 | eletro Galvanized/ hot dip Galvanized |
| Swivel coupler | 48.3x60.5mm | 1380g | yes | Q235/Q355 | eletro Galvanized/ hot dip Galvanized |
| Putlog coupler | 48.3mm | 630g | yes | Q235/Q355 | eletro Galvanized/ hot dip Galvanized |
| Board retaining coupler | 48.3mm | 620g | yes | Q235/Q355 | eletro Galvanized/ hot dip Galvanized |
| Sleeve coupler | 48.3x48.3mm | 1000g | yes | Q235/Q355 | eletro Galvanized/ hot dip Galvanized |
| Inner Joint Pin Coupler | 48.3x48.3 | 1050g | yes | Q235/Q355 | eletro Galvanized/ hot dip Galvanized |
| Beam/Girder Fixed Coupler | 48.3mm | 1500g | yes | Q235/Q355 | eletro Galvanized/ hot dip Galvanized |
| Beam/Girder Swivel Coupler | 48.3mm | 1350g | yes | Q235/Q355 | eletro Galvanized/ hot dip Galvanized |
2. BS1139/EN74 Standard Pressed scaffolding Coupler and Fittings
| Commodity | Specification mm | Normal Weight g | Customized | Raw Material | Surface treatment |
| Double/Fixed coupler | 48.3x48.3mm | 820g | yes | Q235/Q355 | eletro Galvanized/ hot dip Galvanized |
| Swivel coupler | 48.3x48.3mm | 1000g | yes | Q235/Q355 | eletro Galvanized/ hot dip Galvanized |
| Putlog coupler | 48.3mm | 580g | yes | Q235/Q355 | eletro Galvanized/ hot dip Galvanized |
| Board retaining coupler | 48.3mm | 570g | yes | Q235/Q355 | eletro Galvanized/ hot dip Galvanized |
| Sleeve coupler | 48.3x48.3mm | 1000g | yes | Q235/Q355 | eletro Galvanized/ hot dip Galvanized |
| Inner Joint Pin Coupler | 48.3x48.3 | 820g | yes | Q235/Q355 | eletro Galvanized/ hot dip Galvanized |
| Beam Coupler | 48.3mm | 1020g | yes | Q235/Q355 | eletro Galvanized/ hot dip Galvanized |
| Stair Tread Coupler | 48.3 | 1500g | yes | Q235/Q355 | eletro Galvanized/ hot dip Galvanized |
| Roofing Coupler | 48.3 | 1000g | yes | Q235/Q355 | eletro Galvanized/ hot dip Galvanized |
| Fencing Coupler | 430g | yes | Q235/Q355 | eletro Galvanized/ hot dip Galvanized | |
| Oyster Coupler | 1000g | yes | Q235/Q355 | eletro Galvanized/ hot dip Galvanized | |
| Toe End Clip | 360g | yes | Q235/Q355 | eletro Galvanized/ hot dip Galvanized |
3. German Type Standard Drop Forged scaffolding Couplers and Fittings
| Commodity | Specification mm | Normal Weight g | Customized | Raw Material | Surface treatment |
| Double coupler | 48.3x48.3mm | 1250g | yes | Q235/Q355 | eletro Galvanized/ hot dip Galvanized |
| Swivel coupler | 48.3x48.3mm | 1450g | yes | Q235/Q355 | eletro Galvanized/ hot dip Galvanized |
4. American Type Standard Drop Forged scaffolding Couplers and Fittings
| Commodity | Specification mm | Normal Weight g | Customized | Raw Material | Surface treatment |
| Double coupler | 48.3x48.3mm | 1500g | yes | Q235/Q355 | eletro Galvanized/ hot dip Galvanized |
| Swivel coupler | 48.3x48.3mm | 1710g | yes | Q235/Q355 | eletro Galvanized/ hot dip Galvanized |
Product Advantage
One of the main benefits of drop forged coupler is their strength and durability. Made from high-quality steel, these sockets are able to withstand heavy loads, making them ideal for construction projects that require stable support. They comply with British standards, ensuring that stringent safety requirements are met, giving peace of mind to contractors and workers.
In addition, the forged connectors are easy to install and remove, significantly reducing on-site labor time. Their design allows for quick adjustments, making them flexible for a variety of scaffolding configurations. This efficiency is particularly beneficial for companies looking to optimize their workflow and minimize downtime.
Product shortcoming
One notable one is their weight; being made from solid steel, they are heavier than other types of sockets, which can make shipping and handling challenging. This can lead to increased labor costs, especially on large projects where a large number of sockets are required.
Additionally, while forged fittings are durable, they are also susceptible to corrosion if not properly maintained. In environments with high humidity or exposure to harsh chemicals, regular inspection and maintenance are essential to ensure their longevity.
Main feature
Safety and reliability are of utmost importance in the construction industry. One of the key components to ensure these standards are met is the swaged clip. These clips are an integral part of scaffolding systems, especially those that comply with British Standards such as BS1139 and EN74. As a key feature of scaffolding accessories, swaged clips provide the necessary strength and durability for supporting steel pipes in various construction projects.
Designed to withstand heavy loads and harsh environmental conditions, forged scaffolding connectors are the preferred choice of contractors worldwide. Their rugged construction ensures that steel pipes are securely connected to form a stable framework, which is essential for any construction site. Historically, the combination of steel pipes and connectors has been an industry mainstay, providing a reliable solution for scaffolding needs.
Our commitment to quality and customer satisfaction has made us a trusted supplier of drop-forged fasteners and other scaffolding accessories. As we continue to grow, we remain committed to providing innovative solutions to meet the ever-changing needs of the construction industry. Whether you are a contractor looking for reliable scaffolding solutions or a project manager looking to improve site safety, our drop-forged fasteners are ideal for your scaffolding needs.
FAQS
Q1:What is a drop forged joint?
Scaffolding drop forged couplers are accessories used in scaffolding systems to securely connect steel pipes. They are manufactured using a high pressure forming process, making them strong and reliable. These connectors are essential to ensure the stability and safety of scaffolding structures and are the first choice for construction projects.
Q2:Why choose a coupler that complies with BS1139/EN74 standards?
BS1139 and EN74 are British and European standards that set the benchmark for scaffolding accessories. Couplers that meet these standards undergo rigorous quality and performance testing to ensure they can withstand the demands of the construction environment. By using couplers that meet BS1139/EN74 standards, contractors can be confident that they are using a product that complies with strict safety regulations.
Q3:How is the forged fittings market developing?
Since establishing our export company in 2019, our customer base has expanded significantly to nearly 50 countries around the world. This growth reflects the growing demand for high-quality scaffolding products, including forged fasteners. We are committed to building a sound procurement system to effectively meet the diverse needs of our customers.
